GIS Application – SS3 Geography Lesson Note (Second Term)

Lesson note at a glance

Class
SS3
Subject
Geography
Term
Second Term
Reading time
5 min
Start of this note, 1 of 6
Take this term’s notes offline
Reading here is free. Download all 6 SS3 Geography Second term notes as PDF to print and Word to edit.
Download all three terms, ₦2,000
Instant download. Secure payment by Paystack. Card, bank transfer, USSD or OPay. Payment stuck? WhatsApp us.

A Geographic Information System (GIS) is a computer-based system for collecting, storing, analysing and displaying data that has a location on the Earth’s surface.

Behavioural objectives

By the end of the lesson, students should be able to:

Advertisement
  1. Define GIS and name its main components.
  2. Explain the various applications of GIS.
  3. Give a Nigerian example for each major application.
  4. Examine the problems militating against GIS implementation in Nigeria.
  5. Suggest ways of reducing these problems.

Instructional techniques

  • Identification: students pick out the fields in which GIS is used.
  • Explanation: the teacher explains each application and each problem.
  • Questions and answers: short oral checks after each section.
  • Demonstration: the teacher shows a digital map with layers.
  • Videos: clips showing GIS at work.

Instructional materials

  • Videos: short clips on GIS mapping.
  • Loudspeaker: for playing the video sound in a large class.
  • Textbook: an approved SS3 Geography text.
  • Pictures: maps, satellite images and GIS screen displays.

What does a GIS give to decision makers?

A GIS gives decision makers spatial data in the form of maps, tables and reports.

  • Maps: show where features such as roads, rivers and settlements are found.
  • Tables: list the details of each feature, such as its name, size or type.
  • Reports: summarise the results of the analysis so that leaders can act on them.

What are the components of a GIS?

A GIS has five components: hardware, software, data, people and methods.

  • Hardware: computers, GPS receivers, scanners, printers and servers.
  • Software: programs that store, analyse and display map data.
  • Data: location data (spatial) and descriptive data (attribute), such as a road and its name.
  • People: trained users who collect data, run the analysis and read the results.
  • Methods: the rules and procedures followed in handling the data.

What are spatial data and attribute data?

GIS uses two kinds of data: spatial data, which says where a feature is, and attribute data, which says what it is like.

Point Spatial data Attribute data
Meaning The location and shape of a feature on the Earth’s surface. The descriptive facts about that feature.
Answers the question Where is it? What is it, and what is it like?
Example The position and line of a road. The road’s name, width or surface type.
Advertisement

How does a GIS work?

A GIS works by turning collected location data into stored layers that are analysed and shown as maps.

  1. Data is collected from surveys, GPS readings, satellite images and existing maps.
  2. The data is entered into the computer.
  3. The data is stored in a database, with each kind of feature kept as a separate layer.
  4. The layers are analysed, for example by overlaying a flood map on a settlement map.
  5. The results are displayed as maps, charts and reports for decision makers.

What are the applications of GIS?

GIS is applied in eight main fields: planning, environment, health, disaster management, transport, agriculture, telecommunications and education.

Urban and regional planning

  • Land-use mapping: shows which land is used for housing, markets, farms and industry.
  • Infrastructure development: helps planners site roads, schools, water pipes and power lines.
  • Informed decisions: spatial data lets planners compare options before building.
  • Nigerian example: a state planning ministry mapping land use in a fast-growing city such as Lagos.

Natural resource and environmental management

  • Resource monitoring: tracks forests, rivers, minerals and soils.
  • Environmental change: shows changes such as deforestation and desertification over time.
  • Conservation planning: marks areas that need protection.
  • Forestry, water and mining: supports sustainable use of forests, water supplies and mining sites.
  • Nigerian example: tracking the spread of desertification in the far north.

Health and public health

  • Disease mapping: shows where cases of a disease occur.
  • Surveillance and epidemiology: tracks how a disease spreads and identifies high-risk areas.
  • Healthcare access: shows which communities are far from a clinic or hospital.
  • Facility location: helps choose the best site for a new health centre.
  • Nigerian example: mapping cases of cholera or malaria by local government area.

Disaster response and preparedness

  • Vulnerable areas: maps places at risk, such as flood-prone land along river banks.
  • Risk assessment: estimates the people and property that may be affected.
  • Emergency coordination: guides rescue teams and relief materials to affected places.
  • Nigerian example: mapping flood-prone communities along the River Niger and River Benue.
Advertisement

Transport and logistics

  • Route optimisation: finds the shortest or fastest route for vehicles.
  • Traffic management: shows congested roads and junctions.
  • Logistics planning: improves delivery of goods and the efficiency of transport systems.
  • Nigerian example: finding less congested routes for delivery vehicles in Lagos.

Agriculture

  • Precision farming: farmers apply inputs only where the land needs them.
  • Crop yield: spatial data helps raise yields from each plot.
  • Resource management: guides the use of water and fertilisers.
  • Nigerian example: mapping soil types to decide where to plant maize, rice or cassava.

Telecommunications

  • Cell tower placement: picks sites that cover the most users.
  • Network coverage: shows areas with weak or no signal.
  • Nigerian example: a network company locating masts to reach villages with poor signal.

Education

  • Teaching geography: helps students see places, patterns and relationships on maps.
  • Spatial analysis: trains students to analyse location data.
  • Hands-on practice: lets students work with real-world data.
  • Nigerian example: students using digital maps of Nigerian states to study relief and drainage.

What problems limit GIS implementation in Nigeria?

Six main problems limit GIS use in Nigeria: weak infrastructure, poor data, few skilled people, high cost, unclear policies and poor maintenance.

Problem Explanation Possible solution
Inadequate technological infrastructure Unreliable power supply and internet connectivity stop GIS systems from working well. Improve electricity and internet services; use alternative power.
Limited access to accurate, up-to-date spatial data Inconsistent data quality and insufficient coverage reduce the reliability of GIS results. Update maps regularly and set common data standards.
Shortage of skilled GIS professionals Few people are trained to use GIS technology and its applications. Provide more training and education programmes.
High cost Software, hardware and training are costly, especially for smaller organisations. Increase funding; share equipment and data between agencies.
Lack of clear policies and regulations No clear rules on data sharing, access and use slow down adoption. Set up a strong regulatory framework.
Poor maintenance Lack of funds and technical skill prevents regular servicing, which shortens the life of the systems. Budget for maintenance and train technicians.

Evaluation

  1. Define GIS.
  2. List the five components of a GIS.
  3. Mention five applications of GIS across various fields.
  4. Identify five factors militating against GIS implementation in Nigeria.
  5. Suggest one solution to each of two of these problems.

Assignment

Explain how GIS is used in disaster response and in farming, then describe two problems that limit GIS implementation in Nigeria.
